N5762K - 1964 Beechcraft S35

N5762K
N5762K 1964 Beechcraft S35
Here's a hard-to-find "S" Bo in excellent condition. The Fast Bonanza features Garmin 530W WAAS fully coupled the S-Tec 60-2 with GPSS, Yaw Damper and Altitude Pre-Select. Many speed STCs and a giant useful load makes this one of the most sought-after V-Tails. Super comfortable cross-country machine!

Aircraft Specifications

Price:
SOLD

Sale Pending
Serial Number:
D-7550
Total Time Airframe:
6,025 hrs
Engine SFRM:
1,246 hrs
Engine SFRM (2):
0 hrs
Propeller SNEW:
1,246 hrs
Propeller SNEW (2):
0 hrs

Engine and Propeller

Annual Inspection Completed August 2018 Engine Since Factory Rebuilt TCM IO-520-BA10 s/n 822924-R Rebuilt 2005 Propeller: McCauley 2A37C223-C s/n 050077 New 2005 Useful Load: 1,230.50 Lbs MTOW: 3,300 lbs

Interior and Exterior

Dove Gray Leather Seating and Carpets Very Good Condition

Overall Vestal White with Charcoal and Navy Accent Scheme Very Good Condition

Location

KLHZ

Hangared All Logbooks and Records

Avionics

  • S-Tec System 60-2 Autopilot
  • King KCS-55A HSI with Compass Slaving
  • GPSS (Roll Steering)
  • Altitude Hold and Pre-Selector
  • Yaw Damper
  • Electric Pitch Trim
  • Vertical Speed Select
  • Garmin GNS-530W WAAS IFR GPS/NAV/COMM
  • Garmin GMA-340 Audio Panel
  • 4-place intercom
  • Marker Beacons
  • King KX-165 NAV/COMM
  • VOR ‘To-From’ Bearing Display
  • KI-209A VOR/LOC/GS Indicator
  • King KT-79 Digital Mode C Transponder
  • King KR-87 ADF (Inop)
  • Davtron 903 DVOR
  • Davtron OAT
  • Alcor EGT
  • Ground Comm
  • Music Mute
  • Co-Pilot PTT on Panel
  • Avionics Master Switch
  • Northstar M-1 Loran (Defunct)

Features and Equipment

  • STCs
  • Brackett Air FIlter STC
  • Cleveland Wheels and Brakes STC
  • Cygnet Yoke Anti-Theft Clamp STC
  • D’Shannon Speed Slope WIndshield STC
  • D’Shannon Pilot’s Side WIndow STC
  • Smith Aero Stabilizer Stub Spar STC
  • Smith Speed Conversions Aileron Fairings STC
  • Smith Speed Conversions Flap Gap Fairings STC
  • Rosen Visors STC
  • Concorde Battery STC
  • Precise Flight Standby Vacuum SVS-V STC
  • McCauley Prop STC
  • S-Tec Pitch Trim STC
  • S-Tec Yaw Damper STC
  • S-Tec GPSS STC
  • Includes Bruce’s Custom Cover

Photos
